SH 288 Managed Lanes Project maps
SH 288 Managed Lanes Project
SH 288 Managed Lanes Project gantry locations
The SH 288 Managed Lanes Project is comprised of three mainlane toll gantries and eight direct connector toll gantries.
Between US 59 and I-610
- Toll Gantry 1 - mainlanes near Brays Bayou
- Toll Gantry 2 - mainlanes near Holly Hall
- Toll Gantry 8 - direct connector from I-610 to SH 288 northbound
- Toll Gantry 10 - direct connector from SH 288 southbound to I-610
Between I-610 and Beltway 8 (Sam Houston Tollway)
- Toll Gantry 3 - mainlanes near Almeda Genoa
- Toll Gantry 9 - direct connector from SH 288 northbound to I-610
- Toll Gantry 11 - direct connector from I-610 to SH 288 southbound
BW 8 (Sam Houston Tollway) Direct Connectors
- Toll Gantry 4 - direct connector from BW 8 (Sam Houston Tollway) westbound to SH 288
- Toll Gantry 5 - direct connector from SH 288 northbound to BW 8 (Sam Houston Tollway)
- Toll Gantry 6 - direct connector from SH 288 southbound to BW 8 (Sam Houston Tollway)
- Toll Gantry 7 - direct connector from BW 8 (Sam Houston Tollway) eastbound to SH 288
